Model: B860M DS3H WIFI6E
View More Info...
Chat Through
| Supported CPU | LGA1700 socket: Support for 14th, 13th, and 12th Generation Intel® Core, Pentium Gold, and Celeron processors L3 cache varies with CPU |
| Chipset | Intel B860 Express Chipset |
| BIOS | 1 x 128 Mbit flash Licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Form Factor | Micro ATX; 24.4 cm x 24.4 cm |
| Audio | Realtek Audio CODEC High Definition Audio, 2/4/5.1/7.1-channel |
| PCI | PCI Express x16: 1 x PCIe 5.0 x16 slot for graphics card PCI Express x1: 2 x PCIe 3.0 x1 slots |
| Memory Type | DDR5 |
| Max Memory Channels | Up to 128 GB (32 GB per DIMM) |
| Slots | 4 |
| Supported Memory Type | DDR5 6400(O.C.)/6200(O.C.)/6000(O.C.)/5800(O.C.)/5600(O.C.)/5400(O.C.)/5200(O.C.)/4800 MT/s, dual-channel, non-ECC, un-buffered, XMP support |
| HDMI | 1 x HDMI 2.1 port |
| USB (s) | 1 x USB Type-C header, USB 3.2 Gen1 5 x USB 3.2 Gen1 (3 rear, 2 internal) 6 x USB 2.0 (2 rear, 4 internal) |
| LAN Port (s) | Realtek GbE LAN, 1 Gbps |
| Wireless Communication module | Realtek Wi-Fi 6E RTL8851BE, Bluetooth 5.3, 2.4/5/6 GHz |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header, 3 x system fan headers 1 x addressable LED header, 1 x RGB LED header 2 x M.2 connectors, 4 x SATA 6Gb/s connectors Front panel, audio, USB 3.2 Gen1, USB Type-C, USB 2.0 headers Serial, parallel, S/PDIF headers, Q-Flash Plus button, reset & Clear CMOS jumper Back Panel Connectors: 2 x USB 2.0, 3 x USB 3.2 Gen1, 1 x USB Type-C 1 x PS/2 keyboard/mouse port 2 x SMA antenna connectors (Wi-Fi 6E) 1 x DisplayPort, 1 x HDMI port 1 x RJ-45 LAN port 3 x audio jacks |
| TPM (Trusted Platform Module ) | 1 x TPM header (supports GC-TPM2.0 modules) |
| Graphics | Onboard Graphics: Intel UHD Graphics support 1 x HDMI 2.1 port, max resolution 4096×2160 @60Hz 1 x DisplayPort 1.4, max resolution 4096×2304 @60Hz |
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
| Special Features | GIGABYTE Control Center (GCC) support Q-Flash & Q-Flash Plus support |
| Warranty | 3 Years warranty |
GIGABYTE B860M DS3H WIFI6E (rev. 1.0) Intel B860 DDR5 Micro ATX Motherboard Price in bd is an excellent choice for gamers, content creators, and PC enthusiasts looking for high performance and reliability. This Micro ATX motherboard supports the latest 14th, 13th, and 12th Generation Intel® Core processors via the LGA1700 socket, ensuring seamless compatibility and powerful computing performance. Equipped with the Intel B860 Express chipset and licensed AMI UEFI BIOS, it provides stability, efficient power delivery, and advanced system management features for both beginners and professionals. The motherboard comes with 4 DDR5 DIMM slots, supporting up to 128 GB of high-speed memory with dual-channel architecture, XMP support, and overclocking capabilities up to 6400 MT/s. Graphics output is handled via HDMI 2.1 and DisplayPort 1.4, allowing 4K resolution at 60Hz for ultra-clear visuals. Gamers and designers will appreciate the PCIe 5.0 x16 slot for high-end graphics cards and additional PCIe 3.0 x1 slots for expansion cards. Connectivity options include Wi-Fi 6E with Bluetooth 5.3, multiple USB ports (Type-C and USB 3.2 Gen1), and a reliable Realtek GbE LAN port. For storage, it offers 2 M.2 slots with PCIe 4.0 support and 4 SATA 6Gb/s connectors, including RAID 0/1/5/10 compatibility. Other highlights include support for GIGABYTE Control Center (GCC), Q-Flash Plus, addressable RGB headers, and TPM 2.0. Its compact Micro ATX form factor (24.4 cm x 24.4 cm) makes it ideal for small to medium builds without compromising performance. Bundled software like Norton Internet Security and LAN bandwidth management tools further enhance user experience. With a 3-year warranty, the GIGABYTE B860M DS3H WIFI6E ensures long-lasting reliability and robust performance for modern computing needs. This motherboard is perfect for anyone in Bangladesh seeking a high-quality, future-proof platform for gaming, productivity, and multimedia.
The GIGABYTE B860M DS3H WIFI6E is widely available in Bangladesh through leading online platforms and local retailers. Its Micro ATX form factor ensures compatibility with most modern cases, while user-friendly BIOS, Wi-Fi 6E connectivity, and multiple expansion options make installation and daily use seamless for gamers, content creators, and professionals alike.
The GIGABYTE B860M DS3H WIFI6E is competitively priced in Bangladesh, offering excellent value for high-performance gaming and productivity. It provides premium features like DDR5 support, PCIe 5.0, and Wi-Fi 6E connectivity at an affordable range, making it an ideal motherboard choice for budget-conscious and performance-driven users.
Gaming Performance GIGABYTE B860M DS3H WIFI6E Motherboard
Gamers will experience superior performance with the GIGABYTE B860M DS3H WIFI6E. Its PCIe 5.0 x16 slot supports the latest high-end graphics cards, while DDR5 memory ensures ultra-fast loading and multitasking. The motherboard’s robust power delivery, high-speed M.2 SSD support, and HDMI/DisplayPort outputs deliver smooth 4K visuals and lag-free gameplay. Coupled with Wi-Fi 6E, it guarantees low-latency online gaming, making this motherboard a perfect choice for competitive and immersive gaming setups.
The GIGABYTE B860M DS3H WIFI6E delivers an exceptional user experience with intuitive BIOS, fast boot times, and stable system performance. Its multiple USB ports, Wi-Fi 6E, Bluetooth 5.3, and flexible expansion slots make setup effortless. Gamers, professionals, and PC builders benefit from its compact Micro ATX design, easy cable management, and RGB customization options, ensuring smooth and satisfying daily use.
Onix Computer ensures authentic products, genuine warranty support, and expert guidance for installation and troubleshooting. Customers in Bangladesh can trust Onix Computer for reliable delivery, competitive pricing, and excellent after-sales service when purchasing the GIGABYTE B860M DS3H WIFI6E.
Q1: Does this motherboard support DDR5 memory?
A1: Yes, it supports up to 128GB DDR5 memory with XMP overclocking support.
Q2: Can I use Wi-Fi 6E and Bluetooth simultaneously?
A2: Yes, the onboard Realtek Wi-Fi 6E and Bluetooth 5.3 allow simultaneous wireless connectivity.
Q3: Is this motherboard compatible with 14th Gen Intel CPUs?
A3: Yes, it supports 14th, 13th, and 12th Gen Intel Core, Pentium Gold, and Celeron processors.
