PNY GeForce RTX 3060 12GB VERTO Dual Fan GDDR6 Graphics Card

PNY GeForce RTX 3060 12GB VERTO Dual Fan GDDR6 Graphics Card

PNY GeForce RTX 3060 12GB VERTO Dual Fan GDDR6 Graphics Card The PNY GeForce RTX 3060 12GB VERTO Dual Fan Graphics Card allows you to compete in the newest games by utilizing the power of Ampere NVIDIA's 2nd generation RTX architecture. Improved Ray Tracing Cores and Tensor Cores, new streaming multiprocessors, and high-speed G6 memory deliver exceptional performance.

GeForce RTX 3060 Lets You Take On The Latest Games Using The Power Of Ampere—NVIDIA’s 2nd Generation RTX Architecture. Get Incredible Performance With Enhanced Ray Tracing Cores And Tensor Cores, New Streaming Multiprocessors, And High-Speed G6 Memory.

The all-new NVIDIA Ampere architecture includes new second-generation Ray Tracing Cores and third-generation Tensor Cores with increased throughput. The NVIDIA Ampere streaming multiprocessors serve as the foundation for the world's fastest and most efficient GPU for gaming and producers. The GeForce RTX 30 Series GPUs are powered by NVIDIA's 2nd generation RTX architecture, which provides the greatest performance, ray-traced visuals, and AI acceleration for gamers and artists. The GeForce RTX 30 Series GPUs are powered by NVIDIA's 2nd generation RTX architecture, which provides the greatest performance, ray-traced visuals, and AI acceleration for gamers and artists.

PNY GeForce RTX 3060 12GB Graphics Card Features

• MPN: VCG306012DFBPB1

• Model: GeForce RTX 3060 12GB VERTO Dual Fan
• Clock Speed: 1320 MHz, Boost Speed: 1777 MHz
• Memory Speed: 15Gbps
• Memory Interface: 192-bit
• Outputs: 3x DisplayPort 1.4a, HDMI 2.1

Specification

• Clock Speed: 1320 MHz,
• Boost Speed: 1777 MHz
• Memory Speed: 15Gbps
• Memory Interface: 192-bit
• Outputs: 3x DisplayPort 1.4a, HDMI 2.1
• NVIDIA® GeForce RTX™ 3060 (LHR)
• 12 GB GDDR6 (192bit), Connection via PCIe 4.0
• Active Cooling (Dual-Slot)
• 1x HDMI, 3x DisplayPort
• Power Supply: 1x 8pin, 550 W PSU recommended
• Card length approx. 247 mm

PNY GeForce RTX 3060 12GB GDDR6 Graphics Card View

Brand - PNY, Chipset Vendor - NVIDIA GeForce, Series - RTX 3000, Chipset Model - GeForce RTX 3060, Model - PNY GeForce RTX 3060, CUDA Core / Stream Processors - 3584  (CUDA), Base Engine Clock Speed - 1320 MHz, Boost Engine Clock Speed - 1777 MHz, Memory Clock - 15Gbps, Memory Size - 12GB, Memory Bus - PCI-Express 4.0 x16, Memory Bandwidth - 360, Memory Type - GDDR6, Interface - 192 bit, Digital Max Resolution - 7680 x 4320, DirectX - 12 Ultimate, OpenGL - 4.6, VGA Port - No, DVI Port - No, HDMI Port - 1, Display port - 1.4, Power Consumption - 170W, Recommended PSU - 550W, Power Connectors - 1 x 8-pin, Multi Display Capability - Quad Display, Card Dimension - 247.39 x 118.364 x 40.64mm, HDCP Support - Yes (2.3), Cooling Fan - Dual Fan, Others - The GeForce RTX 3060 lets you take on the latest games using the power of Ampere NVIDIA`s 2nd generation RTX architecture. Get incredible performance with enhanced Ray Tracing Cores and Tensor Cores, new streaming multiprocessors, and high-speed G6 memory., Specialty - 2nd Gen Ray Tracing Cores, 3rd Gen Tensor Cores, PCI Express Gen 4, Microsoft DirectX 12 Ultimate, Game Ready Drivers Vulkan RT API, OpenGL 4.6 HDCP 2.3 VR Ready Supports 4k 120Hz HDR, 8K60Hz HDR, and Variable Refresh Rate as specified in HDMI 2.1, Part No - VCG306012DFBPB1

PNY GeForce RTX 3060 12GB VERTO Graphics Card Overview

GeForce RTX 30 Series GPUs Are Powered By NVIDIA’s 2nd Gen RTX Architecture, Delivering The Ultimate Performance, Ray-Traced Graphics, And AI Acceleration For Gamers And Creators

NVIDIA Ampere Streaming Multiprocessors

GeForce RTX 3060 Building Blocks For The World’s Fastest, Most Efficient GPU, The All-New Ampere SM Brings 2X The FP32 Throughput And Improved Power Efficiency.

2nd Generation RT Cores

Experience 2X The Throughput Of 1st Gen RT Cores, Plus Concurrent RT And Shading For A Whole New Level Of Ray Tracing Performance.

3rd Generation Tensor Cores

Get Up To 2X The Throughput With Structural Sparsity And Advanced AI Algorithms Such As DLSS. Now With Support For Up To 8K Resolution, These Cores Deliver A Massive Boost In Game Performance And All-New AI Capabilities.

Step up to GeForce GTX. It brings you performance that’s up to 50% faster than the original GTX 16 Series and up to 2X faster than previous-generation 10 Series GPUs. It’s time to gear up and get SUPER. The PNY GeForce 6GB Single Fan GDDR6 Graphics Card offers best-in-class performance with the advanced graphics capabilities of the award-winning NVIDIA Turing architecture. Concurrent execution of floating-point and integer operations, adaptive shading technology, and a new unified memory architecture enable awesome performance increases in today’s games. State-of-the-art graphics features, including variable-rate shading, mesh shading, and multi-view rendering.

GeForce RTX 3060 All-New NVIDIA Ampere Architecture Features New 2nd Generation Ray Tracing Cores And 3rd Generation Tensor Cores With Greater Throughput. The NVIDIA Ampere Streaming Multiprocessors Are The Building Blocks For The World’s Fastest, Most Efficient GPU For Gamers And Creators. GeForce RTX™ 30 Series GPUs Are Powered By NVIDIA’s 2nd Gen RTX Architecture, Delivering The Ultimate Performance, Ray-Traced Graphics, And AI Acceleration For Gamers And Creators.

PNY GeForce RTX 3060 12GB Graphics Card Quick Overview

• Chipset - NVIDIA GeForce
• HDMI Port - 1
• Capacity (GB/TB) - 6GB
• Graphics Resolution Max. - 7680 x 4320
• Multi Display Capability - Triple Display

PNY GeForce RTX 3060 12GB Graphics Card Review

The physical design doesn’t include any fancy extras either. You won’t find a backplate, a dual BIOS switch, or flashy RGB lights like you do on the Asus Dual EVO OC.

GeForce RTX 3060 lets you take on the latest games using the power of Ampere—NVIDIA’s 2nd generation RTX architecture. Get incredible performance with enhanced Ray Tracing Cores and Tensor Cores, new streaming multiprocessors, and high-speed G6 memory.

The all-new NVIDIA Ampere architecture features new 2nd generation Ray Tracing Cores and 3rd generation Tensor Cores with greater throughput. The NVIDIA Ampere streaming multiprocessors are the building blocks for the world’s fastest, most efficient GPU for gamers and creators.

GeForce RTX 3060 Series GPUs are powered by NVIDIA’s 2nd gen RTX architecture, delivering the ultimate performance, ray-traced graphics, and AI acceleration for gamers and creators.

Here’s how things break down, comparing the RTX 3060 with its closest Ampere sibling and Turing predecessors. The RTX 2060 and 2060 Super show how much things have changed for the -60 suffix cards between Turing and Ampere. Ampere gives you a lot more shader cores that for the RTX 3050 line) and boasts improvements in the RT and Tensor cores, as well as the memory subsystem, all leading to better performance. Power use remains similar, with a 170W TGP (Total Graphics Power), a decent step down from the RTX 3060 Ti’s 220W TGP.

One interesting tidbit is that this is the first time Nvidia has used 15Gbps GDDR6 memory. The RTX 20-series cards all used 14Gbps memory, except for the RTX 2080 Super that came equipped with 15.5Gbps VRAM. That narrows the bandwidth gap between the 3060 and 3060 Ti a bit, though the extra 64-bits of interface width still gives the GA104 cards a clear advantage. And GA106 doesn’t have an advantage is in ROPs, Render Outputs, as it only has 48 — the same as the RTX 2060.

However, the differences between Turing and Ampere GPUs don’t always show up in specs tables like the above. Theoretically, the RTX 3060 has up to 95% more FP32 performance and 97% more FP16 Tensor core performance than the RTX 2060. In practice, the actual performance difference is much less, as half of the FP32 pipelines share processing resources with INT32 pipelines. The 3060 shouldn’t ever be slower for gaming purposes, but most of the time, it will only be around 20-25 percent faster.

None of that makes this a bad GPU, but we expect the RTX 3060 to be just as difficult to acquire as any other modern GPU. Eventually, the current Ethereum mining boom will fade away, but it could take a year or more before we see the end of chip shortages. That shouldn’t surprise anyone at this point, but if you’ve been hoping for a reasonably priced gaming PC upgrade, it’s a depressing state of affairs.

Unlike the previous Ampere GPUs, Nvidia won’t offer an RTX 3060 Founders Edition, so we’re looking at a third-party card. Nvidia shipped us the EVGA GeForce RTX 3060 XC for this launch review, a reasonably compact and relatively unassuming card. There’s no metal (or even plastic) backplate, no RGB lighting, and two custom-sized 87mm fans for cooling with a 2.0-slot form factor. The card measures 202x110x38mm and weighs 653g, which is quite the change of pace compared to the other third-party Ampere cards we’ve reviewed so far.
