Model: PRO B760M-P
View More Info...
| Type | DDR5 |
| Supported CPU | Supports 14th/12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700 |
| Chipset | INTEL B760 |
| Form Factor | mATX 220mmx243.84mm |
| Audio | Realtek ALC897 Codec 7.1-Channel High-Definition Audio |
| PCI | 1x PCI-E x16 slot 2x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to (From CPU) PCI_E2 Gen PCIe 4.0 supports up to (From Chipset) PCI_E3 PCIe 4.0 supports up to x1 (From Chipset) |
| Memory Size | 192GB |
| Slots | 4 x DIMM |
| Supported Memory Type | Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 6800+ MHz • 1DPC 2R Max speed up to 6400+ MHz • 2DPC 1R Max speed up to 6000+ MHz • 2DPC 2R Max speed up to 5600+ MHz Supports Intel XMP 3.0 OC Supports Dual-Controller Dual-Channel mode Supports non-ECC, un-buffered memory |
| HDMI | 1x HDMI 2.1 |
| Display Port (s) | 1x DisplayPort 1.4 |
| USB (s) | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 1x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 1x USB 3.2 Gen2 Type C (Rear) |
| LAN Port (s) | Intel 2.5Gbps LAN |
| Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| Audio | Audio Connectors |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports |
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) |
| Graphics | 1x HDMI Support HDMI 2.1 with HDR, maximum resolution of 4K 60Hz 1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz* 1x VGA Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz |
| Manufacturing Warranty | 3 Years |
Building a reliable and future-ready PC starts with choosing the right motherboard—and the MSI PRO B760M-P DDR5 mATX Motherboard is designed to deliver exactly that. Whether you are planning a powerful office workstation, a content creation setup, or a smooth mid-range gaming rig, this motherboard provides the perfect balance between performance, stability, and long-term upgrade potential. Engineered with the latest Intel B760 chipset, this board supports 12th and 13th Gen Intel processors, ensuring exceptional multitasking capability and system responsiveness. The integration of next-generation DDR5 memory support allows users to experience faster data processing speeds, improved bandwidth, and better overall system efficiency compared to previous DDR4 platforms. This makes it an excellent choice for users who want modern performance without stepping into extreme high-end pricing.
The compact micro-ATX (mATX) form factor ensures flexibility for various PC case builds, making it suitable for both compact and standard desktop setups. Despite its smaller size, the MSI PRO B760M-P DDR5 mATX Motherboard does not compromise on essential connectivity, offering multiple expansion slots, high-speed storage options, and advanced thermal solutions for stable operation under heavy workloads. With MSI’s trusted build quality and user-friendly BIOS interface, this motherboard is ideal for beginners and experienced builders alike. If you are looking for a dependable foundation for your next-generation PC build, this board stands out as a smart and performance-oriented choice.
The MSI PRO B760M-P DDR5 mATX Motherboard is an excellent choice for users who want performance, stability, and future upgrade flexibility in one package. Whether for office work, content creation, or gaming, it provides a solid foundation for your next PC build. Invest in a motherboard that ensures both efficiency and long-term reliability.
If you’re planning to build a reliable and future-ready PC, the MSI PRO B760M-P DDR5 mATX Motherboard is a strong foundation. For users who need built-in wireless connectivity, you can also explore the relevant product MSI B760M BOMBER WIFI mATX Motherboard, which offers added flexibility for modern networking needs. Both models are ideal choices under the intel Motherboard category, ensuring compatibility with the latest Intel processors and advanced performance features. As part of the trusted MSI lineup, these motherboards deliver stability, durability, and next-generation DDR5 memory support for enhanced speed and efficiency. Whether you're building a gaming PC, office workstation, or productivity setup, MSI B760M series boards provide the performance balance you need. You can find these genuine MSI motherboards at Onix BD, a reliable destination for authentic tech products in Bangladesh. Choose the right motherboard today and build your system with confidence, performance, and long-term upgrade potential in mind.
