MSI B450 GAMING PLUS MAX AM4 AMD ATX Motherboard
- Price: 13,400৳
- Stock: In Stock
- Brand: MSI
- Model: MSI B450 GAMING PLUS MAX
- Product ID: 1503
13,400৳
EMI starts at 4,699৳/month. View all 25 banks EMI plans >
অর্ডার করার আগে স্টক এবং দাম সম্পর্কে নিশ্চিত হয়ে নিন : 01885938356
MSI B450 GAMING PLUS MAX AM4 AMD ATX Motherboard
MSI B450 GAMING PLUS MAX AM4 ATX Motherboard supports 3rd generation AMD Ryzen processors with the AM4 socket. Its four memory slots support a max of 64GB of DDR4 RAM that can be overclocked up to 4133 MHz. For storage, there are six SATA III ports as well as an M.2 slot utilizing the PCIe 3.0 x4 interface. While the motherboard is equipped with DVI-D and HDMI outputs for integrated graphics, it also has a PCIe 3.0 x16 slot for a dedicated graphics card. Other notable integrated features include Realtek ALC 892 7.1-Channel HD Audio and Realtek 8111H Gigabit LAN. This motherboard features PCIe steel armor and slot to protect GPUs from bending and EMI. Equipped with Core Boost, DDR4 Boost, Turbo M.2, a Flash BIOS button, and a USB 3.2 Gen 2 connector, the B450 GAMING PLUS MAX provides the performance you need to build your own gaming rig.
The MSI also adopts the modern style to design the heatsink through huge surface and sleek but simple cuts in order to make the heatsink and appearance looks ripped and powerful. In this motherboards, MSI Mystic Light provides a complete function to control the RGB light all around the ecosystem. Select the available colors from the palette to match your favorite and mood. This AMD motherboards also combined with neutral color, such as black, grey and silver, as the main background, MSI motherboard can perfect fit different RGB LED effects and strongly shows the gamers tunes. The MSI B450 GAMING PLUS MAX Motherboard comes with 03 years of warranty.
MSI B450 GAMING PLUS MAX Banefit
- STAY COOL FOR RELIABLE SYSTEM
- Cooling your PC is essential for reliable performance. MSI B450 GAMING PLUS MAX motherboards feature excellent power design with solid and heavy heatsink. We've made sure to include enough fan headers with full control to allow you to cool your system any way you want.
- APPS TO GREATLY IMPROVE EFFICIENCY
- With years of experience in creating performance enhancing tools that are easy to use, only the highest quality applications are at your disposal. Use these tools to get the most out of your motherboard and achieve victory when gaming. Moreover, we made sure our BIOS contains all the latest options and is easy to use for everyone. The extensive features let you fine-tune your system to deliver reliable maximum performance.
- MAXIMUM COMPATIBILITY
- Every MSI motherboards are certified by strict mechanic that feature convenient pin-header keep out zone, friendly SATA & USB location for compatibility with the widest range of components and devices, so DIY user can pick and choose the components they want. More than that, we offer a dedicated Qualified Vendor List (QVL) for the most critical part - memory. Combining with MSI DDR4 Boost technology, we provide the maximum compatibility even over clocking, so you confirm and choose any gaming rig as you want.
- ENHANCED PERFORMANCE
- MSI B450 GAMING PLUS MAX motherboards featured all the latest solution for enthusiast gamers and prosumers. CPU and memory enhancement and fast storage and USB transfer speed are ready to be on the battlefield.
- CPU
- Power on your RYZEN processor with optimized circuit layouts and high quality power delivery parts for an incredibly stable operation.
- MEMORY
- Optimized layout design and a fully isolated memory circuitry ensures perfect stability and performance. You never have to worry about your system crashing during games with MSI DDR4 BOOST.
- STORAGE
- MSI B450 GAMING PLUS MAX motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Start games faster, load levels faster and have a real advantage over your enemies.
- AUDIO
- Reward your ears with studio grade sound quality. MSI Audio Boost delivers the highest sound quality through the use of premium quality audio components. This lets you enjoy breathtaking, studio quality sound to create the most immersive sound experience.
FEATURES:
- Supports 1st, 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics / Athlon™ with Radeon™ Vega Graphics Desktop Processors for Socket AM4
- Supports DDR4 Memory, up to 4133(OC) MHz
- Lightning Fast Game experience: TURBO M.2, AMD Turbo USB 3.2 GEN2, StoreMI Technology
- Core Boost: With premium layout and fully digital power design to support more cores and provide better performance
- DDR4 Boost: Advanced technology to deliver pure data signals for the best gaming performance and stability
- Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience
- Flash BIOS Button: Simply use a USB key to flash any BIOS within seconds, without installing a CPU, memory or graphics card
Additional Features
- Flash BIOS Button
- Gaming Device Port
- LAN Port
- AMD Turbo USB 3.2 Gen2
- Golden Audio Jacks
- Core Boost supports more cores and provides better performance.
- Gaming heatsinks with Passion Red scheme for maximum cooling and performance
- DDR4 Boost Optimized traces and isolated memory circuitry
- Turbo M.2 NVMe support, up to 32 Gb/s using PCI-Express Gen3 x4, Supports STORE MI
- PCI-E Steel Armor Protecting VGA cards against bending and EMI
- PCI-E Steel Slot Protecting VGA cards against bending
- Audio Boost with amplifier Optimized gaming audio using best components, with Nahimic3
Msi b450 gaming plus max price in bd
This AMD MSI motherboard is built with Flash BIOS Button, Gaming Device Port, LAN Port, AMD Turbo USB 3.2 Gen2 and Golden Audio Jacks. In this motherboard the Core Boost supports more cores and provide better performance. Gaming heatsinks with Passion Red scheme for maximum cooling and performance, DDR4 Boost optimized traces and isolated memory circuitry, Turbo M.2 NVMe support, up to 32 Gb/s using PCI-Express Gen3 x4, Supports STORE MI. The PCI-E Steel Armor protecting VGA cards against bending and EMI and PCI-E Steel Slot protecting VGA cards against bending and Audio Boost is built with amplifier which optimized gaming audio using best components, with Nahimic3. MSI motherboards are designed to make the system assembly process as convenient as possible.
Msi b450 gaming plus max review:
The MSI B450 GAMING PLUS MAX motherboard offers a solid foundation for mid-range gaming rigs. With its AM4 socket, it supports AMD Ryzen processors and DDR4 memory, providing reliable performance. Featuring PCIe 3.0 slots, M.2 support, and USB 3.2 ports, it offers versatile connectivity options. The board's robust VRM design and extended heatsink ensure efficient cooling for stable overclocking. Though lacking some modern features like PCIe 4.0, its affordability and compatibility with previous-gen Ryzen CPUs make it a practical choice for gamers seeking a balance between performance and cost in a reliable motherboard.
