| Supported CPU | LGA1700 socket: Support for 12th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors L3 cache varies with CPU |
| Chipset | Intel Z690 Express Chipset |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm |
| Audio | Realtek ALC1220-VB CODEC * The back panel line out jack supports DSD audio. High Definition Audio 2-channel analog output Support for S/PDIF Out 7.1-channel digital signals |
| PCI | 1 x PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 5.0 standard.) 2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2) (The PCIEX4 slots conform to PCI Express 3.0 standard.) |
| M.2 Socket | 4 x Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Enlarged Thermal Guards |
| Memory Type | DDR5 |
| Slots | 4 x DIMM |
| Supported Memory Type | Support for DDR5 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MHz memory modules Dual-channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
| Max. Memory | Up to 128 GB (32 GB single DIMM capacity) |
| HDMI | 1 x HDMI port |
| USB (s) | Chipset: 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2x2 support 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) |
| LAN Port (s) | Intel 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Supported Storage | CPU: 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 2 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB) 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB) 6 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 * Refer to "2-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors. Intel Optane Memory Ready * System acceleration with Intel Optane Memory can only be enabled on the M.2 connectors supported by the Chipset. |
| Audio | 1 x front panel audio header |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 4 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt add-in card connectors 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x reset button 1 x reset jumper 1 x Q-Flash Plus button 1 x Clear CMOS jumper |
| Graphics | Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.0 version and HDCP 2.3. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies |
| Special Features | Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup System Information Viewer Support for Q-Flash Plus Support for Q-Flash Support for Xpress Install |
| Manufacturing Warranty | 3 years |
Accelerate Your PC's Power With The Z690 Gigabyte Gaming Motherboards. The Next Era Of Gaming Platforms Continues With The Most Robust Power Delivery And Dominant Thermal Design, Glorified With The Complete Memory Overclocking Technology To Crown Your PC With The Best Performance. With Technology Moving So Fast, GIGABYTE Still Keep Up With The Latest Trends And Provide Customers With Advanced Features And The Latest Technology. GIGABYTE Z690 Series Motherboards Come With Upgraded Power Solutions, The Latest Storage Standards And Outstanding Connectivity To Enable Optimized Performance For Gaming.
SPEEDS LIKE NO OTHER
GIGABYTE Z690 Motherboards Are Ready To Work With The Upcoming PCIe 5.0 Devices Which Are Expected To Experience Double Bandwidth Than The Current PCIe 4.0 Devices. To Reach The High Speed And Maintain Good Signal Integrity, GIGABYTE R&D Uses The Low Impedance PCB To Provide The Maximum Performance.
IMPRESSIVE MEMORY PERFORMANCE
GIGABYTE Is Offering A Tested And Proven Platform That Ensures Proper Compatibility With Profiles Up To 5333MHz And Beyond. All Users Need To Do To Attain This Performance Boost Is To Ensure That Their Memory Module Is XMP Capable And That The XMP Function Is Activated And Enabled On Their GIGABYTE Motherboard.
FOR EVERY CONNECTION
GIGABYTE Z690 Series Motherboards Let You Experience Ultimate Connection Flexibility And Blazing Data-Transfer Speed With Next Generation Network And Storage Connectivity.
2X FASTER THAN EVER
Adoption Of 2.5G LAN Provide Up To 2.5 GbE Network Connectivity, With At Least 2X Faster Transfer Speeds Compared To General 1GbE Networking, Perfectly Designed For Gamers With Ultimate Online Gaming Experience.
HI-RES AUDIO
Hi-Res Audio Certified, Meaning That The Product Is Capable Of Reproducing Frequencies Up To 40kHz Or Above Which Ensures User With The Best Audio Quality At All Times.
REALTEK HIGH-END HD AUDIO CODEC
Supports Audio Format Up To 32-Bit/384KHz And Output SNR Up To Rear/Front 120dB 110dB.
Automatically Detects Impedance Of Audio Device, Preventing Low Volume And Distortion.
Stream Voice With Up To 110dB(A) SNR Via Microphone.
IMPRESSIVE PERSONALIZATION
GIGABYTE Motherboards Bundle Several Useful And Intuitive Software To Help Users To Control Every Aspect Of Motherboard And Provide Customizable Lighting Effect With Outstanding Aesthetics To Fit Your Unique Personality.
Q-FLASH PLUS
With GIGABYTE Q-Flash Plus, You Don’t Need To Install The CPU, Memory And Graphics Card Nor Enter The BIOS Menu To Flash The BIOS. Just Download And Save A New BIOS File (Rename To Gigabyte.Bin) On The USB Flash Drive, Then Press The Dedicated Q-Flash Plus Button And You’re Good To Go!
