- Stock: In Stock
- Model: B650 EAGLE AX
- Supported CPU: Ryzen 8000/ 7000 Series Processors for Socket AM5
- Supported RAM: 4x DDR5, up to 192GB, 7600(OC)
- Graphics Output: 1x Display Port, 1 x HDMI
- Features: Realtek GbE LAN chip & Realtek Wi-Fi 6E RTL8852CE
| Basic Information | |
| Supported CPU | AMD Socket AM5, support for: AMD Ryzen 8000/ 7000 Series Processors |
| Chipset | AMD B650 |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
| Expansion Slots | |
| PCI | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: - AMD Ryzen 7000 Series Processors support PCIe 4.0 x16 mode - AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode - AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. 2 x PCI Express x16 slots (PCIEX1_1/PCIEX1_2), integrated in the CPU, supporting PCIe 3.0 and running at x1 * The PCIEX1_1 and PCIEX1_2 slots become unavailable when an AMD Ryzen™ 8000 Series-Phoenix 2 processor is used. 1 x PCI Express x16 slot (PCIEX1_3), integrated in the Chipset, supporting PCIe 3.0 and running at x1 |
| Memory Specifications | |
| Memory Type | DDR5 |
| Memory Size | 192GB |
| Slots | 4 DIMMs |
| Supported Memory Type | 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.) |
| Connector & Ports | |
| HDMI | 1x HDMI |
| Display Port (s) | 1 x DisplayPorts |
| USB (s) | CPU: - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel - 1 x USB Type-C port on the back panel, with USB 3.2 Gen 1 support CPU+USB 2.0 Hub: - 4 x USB 2.0/1.1 ports on the back panel Chipset: - 2 x USB 3.2 Gen 1 ports available through the internal USB header - 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header - 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) Chipset+USB 2.0 Hub: - 4 x USB 2.0/1.1 ports available through the internal USB headers |
| LAN Port (s) | Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) |
| Wireless Communication module | Realtek Wi-Fi 6E RTL8852CE - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11ax 160MHz wireless standard (Actual data rate may vary depending on environment and equipment.) |
| Supported Storage | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: - AMD Ryzen 7000 Series Processors support PCIe 5.0 x4/x2 SSDs - AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs - AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs 1 x M.2 connector (M2P_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs: - AMD Ryzen 7000 Series Processors support PCIe 4.0 x2 SSDs - AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x2 SSDs - AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) 4 x SATA 6Gb/s connectors |
| Audio | 3 x Audio jacks |
| Internal I/O Ports | Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x CPU fan/water cooling pump header 2 x system fan headers 1 x system fan/water cooling pump header 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 3 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 3 x USB 2.0/1.1 headers 1 x Q-Flash Plus button 1 x serial port header j 1 x Clear CMOS jumper Back Panel Connectors 1 x DisplayPort 1 x HDMI port 1 x PS/2 keyboard/mouse port 2 x SMA antenna connectors (2T2R) 1 x USB Type-C port, with USB 3.2 Gen 1 support 2 x USB 3.2 Gen 2 Type-A ports (red) 6 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) |
| Graphics | |
| Graphics | Integrated Graphics Processor with AMD Radeon™ Graphics support: - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 1.4 version. - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support for native HDMI 2.1 TMDS compatible ports. (Graphics specifications may vary depending on CPU support.) |
| Others Information | |
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
| Special Features | Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus |
| Warranty Information | |
| Manufacturing Warranty | 3 Years |
Best GIGABYTE B650 EAGLE AX Price in BD | Onix Computer
GIGABYTE B650 EAGLE AX DDR5 AM5 Motherboard is designed to support AMD's latest Ryzen 7000 and 8000 series processors, offering unparalleled performance for both gaming and professional applications. This motherboard features a robust 12+2+2 phase digital VRM solution, ensuring stable power delivery and efficient performance under heavy workloads. With its dual-channel DDR5 memory support, the board includes 4 SMD DIMM slots compatible with AMD EXPO and Intel XMP memory modules, providing enhanced performance and flexibility. The motherboard's SuperSpeed storage features, which include two PCIe 4.0 M.2 and one PCIe 5.0 M.2 connection, allow for quick data access and transfer. VRM power stability and excellent performance for 25110 M.2 SSDs are guaranteed by its sophisticated thermal design, which includes an M.2 thermal protection. With its rapid-release design and hassle-free maintenance and upgrades, the EZ-Latch PCIe x16 slot makes expansion simple. Gigabit Ethernet LAN for dependable wired networking and Wi-Fi 6E 802.11ax for quick wireless connectivity are examples of networking capabilities.
GIGABYTE B650 EAGLE AX price in Bangladesh typically starts from around 22,000৳–32,000৳, depending on stock availability and warranty support. This competitive pricing makes it a perfect choice for gamers, content creators, and PC builders seeking a high-performance AM5 motherboard with Wi-Fi 6E support. Its strong performance, DDR5 memory compatibility, PCIe 5.0 expansion, dual M.2 Gen4 slots, and integrated Wi-Fi 6E make it ideal for modern gaming, streaming, and productivity setups. Onix Computer offers genuine products, full warranty service, and fast delivery across Bangladesh, making it a trusted source for purchasing the GIGABYTE B650 EAGLE AX motherboard.
Key Features of GIGABYTE B650 EAGLE AX
The GIGABYTE B650 EAGLE AX is a premium ATX motherboard for AMD AM5 processors. It supports Ryzen 7000 and 8000 Series CPUs, DDR5 memory, and PCIe 5.0 GPUs. The motherboard includes dual M.2 slots, Wi-Fi 6E connectivity, advanced thermal design, and multiple fan headers for gaming and professional builds. Its robust construction and user-friendly BIOS make it suitable for both beginners and advanced PC builders.
- AM5 CPU Support: Compatible with AMD Ryzen 7000/8000 Series processors for high-performance gaming and multitasking.
- DDR5 Memory Support: Supports up to 192GB DDR5 RAM across 4 DIMM slots with high-speed overclocking.
- PCIe 5.0 Expansion: Full-speed PCIe 5.0 x16 slot for next-gen GPUs and high-performance components.
- Dual M.2 PCIe 4.0 Slots: Supports ultra-fast NVMe SSDs with two M.2 connectors plus 4 SATA ports.
- Wi-Fi 6E & 2.5GbE LAN: Built-in Wi-Fi 6E and Realtek 2.5GbE LAN for stable high-speed networking.
- High-Resolution Display Output: Includes HDMI 2.1 supporting 4K displays and multiple display configurations.
- Advanced Cooling & RGB Support: Multiple fan headers, ARGB/RGB headers, and GIGABYTE Control Center support.
Why Should You Buy a GIGABYTE B650 EAGLE AX From Onix Computer?
Onix Computer offers 100% genuine GIGABYTE motherboards with full warranty and fast delivery across Bangladesh. The B650 EAGLE AX ensures strong performance, DDR5 memory, PCIe 5.0, dual M.2 slots, and integrated Wi-Fi 6E. Whether you are searching for AM5 motherboard price in Bangladesh, AMD gaming motherboard price in BD, or Gigabyte AMD desktop motherboard price BD, Onix Computer provides trusted service and competitive deals. Visit your nearest showroom or browse their online store to explore the latest GIGABYTE motherboards, get the best offers, and enjoy expert support. Other alternatives include GIGABYTE B650 UD AC.
What is the price of the GIGABYTE B650 EAGLE AX in Bangladesh?
The price ranges from around 22,000৳–32,000৳ depending on stock and warranty.
Where can I buy it?
You can buy it from Onix Computer with full warranty and fast delivery.
Does it support RAM upgrades?
Yes, it supports DDR5 RAM for high-speed performance and multitasking.
Is it good for gaming and productivity?
Yes, ideal for gaming PCs, streaming setups, and professional workstation builds.
What ports are available?
Includes USB Type-A, USB Type-C, HDMI 2.1, PCIe 5.0 slots, LAN, Wi-Fi 6E, and multiple fan/RGB headers.
