- Deepcool PN650M 650W Full Modular ATX 3.1 80 Plus Gold Certified Black Power Supply
- Stock: In Stock
- Model: Deepcool PN650M
- SKU: R-PN650M-FC0B-UK
- Maximum Power - 650 Watt
- Type - ATX12V V3.1
- PSU Category - Full Modular
- Efficiency - 90% Efficiency
| Key Features | |
| MTBF | 100,000 Hours |
| Efficiency | 90% Efficiency |
| Fan Size | 120mm |
| General | |
| Type | ATX12V V3.1 |
| Additional Info | |
| PSU | Full Modular |
| Other Features | |
| Specialty | DeepCool PN650M is a new power supply that meets the latest Intel ATX 3.1 and PCIe 5.1 standard. With a dedicated 12V-2x6, 5 EPS/PCIe ports, the PN650M provides stable power for a wide range of modern high-power components. |
| Connector | |
| PCI-E | 3 |
| SATA | 2 |
| Temperature | |
| Operating Temperature | 0 Degree C - 40 Degree C |
| Others Information | |
| Others | Fan Bearing: Fluid Dynamic Bearing Efficiency Rating: 80 Plus Gold Power Good Signal: 100-150ms Hold Up Time: >=16ms (80% Load) Protection: OPP/ OVP/ SCP/ OTP/ OCP/ UVP/ SIP/ NLO Over Voltage Protection (OVP): Yes Over Power Protection (OPP): Yes Over Current Protection (OCP): Yes Over Temperature Protection (OTP): Yes Short Circuit Protection (SCP): Yes Under Voltage Protection (UVP): Yes Maximum Power: 650 Watt Topology: Active PFC + Full Bridge SRC LLC + DC to DC, Capacitors: Japanese Bulk Capacitor, Efficiency: >=90% Under Typical Load(50% Loading), Erp Regulation: ErP 2014, Main Power Connector (20+4)Pin x 1, CPU(4+4)Pin x 2, 2V-2x6(16Pin) x 1. Country Of Origin: China Made in/ Assemble: China |
| Physical Specification | |
| Form Factor | ATX |
Deepcool PN650M 650W Full Modular ATX 3.1 80 Plus Gold Certified Black Power Supply
The Deepcool PN650M 650W Full Modular ATX 3.1 80 Plus Gold Certified Black Power Supply is a highly efficient and reliable power solution designed to meet the needs of modern high-performance systems. With an 80 Plus Gold certification, it delivers up to 90% efficiency at typical loads, reducing energy consumption and heat generation while ensuring consistent, stable power delivery to your components. Built to adhere to the latest ATX 3.1 and PCIe 5.1 standards, the PN650M is optimized to support the demands of the newest technologies. It features a fully modular design, allowing users to connect only the cables they need, which leads to a cleaner, more organized build with better airflow and ease of installation. The PSU comes equipped with essential connectors, including 3 PCIe connectors, 2 SATA power connectors, and a 12V-2x6 for high-powered components. To ensure long-term durability and stable operation, the Deepcool PN650M incorporates a fluid dynamic bearing 120mm fan, which provides efficient cooling with low noise levels. The advanced protection suite includes Over Voltage Protection (OVP), Over Power Protection (OPP), Short Circuit Protection (SCP), and other safeguards that help prevent damage to both the power supply and your system during power fluctuations or other electrical issues. The PSU also uses Japanese bulk capacitors, known for their superior quality and longevity, ensuring reliable performance over extended periods. With an MTBF of 100,000 hours and backed by a generous 10-year warranty, the Deepcool PN650M is designed to provide lasting performance and peace of mind. In terms of size and design, the compact 150 x 140 x 86mm form factor makes it suitable for a wide range of PC builds, and its black color adds a sleek, professional look to your setup.
Deepcool PN650M 650W Full Modular ATX 3.1 80 Plus Gold Certified Black Power Supply Features
- 80 Plus Gold Certified Efficiency: Achieves up to 90% efficiency under typical load, ensuring low energy waste and reduced heat output.
- Fully Modular Design: Allows users to connect only the necessary cables, reducing clutter and improving airflow inside the PC case.
- ATX 3.1 and PCIe 5.1 Compatibility: Supports the latest standards, providing reliable power for high-performance components and future-proofing your build.
- Advanced Cooling: Equipped with a 120mm fluid dynamic bearing fan that offers efficient, quiet cooling for extended usage.
- Comprehensive Protection Suite: Includes Over Voltage Protection (OVP), Over Power Protection (OPP), Over Current Protection (OCP), Short Circuit Protection (SCP), Under Voltage Protection (UVP), and more to safeguard your system.
- High-Quality Components: Features Japanese bulk capacitors for improved reliability and durability.
- Multiple Connectors: Comes with 3 PCIe connectors, 2 SATA power connectors, and a 12V-2x6 (16-pin) connector to support a variety of modern high-powered devices.
- 10-Year Warranty: Backed by a long warranty period, reflecting its durable build quality and reliable performance.
- Compact Form Factor: With dimensions of 150 x 140 x 86mm, it fits in a wide range of PC cases.
- Stable Power Delivery: Ensures steady power output with a hold-up time of ≥16ms under 80% load, preventing potential power interruptions.
