- Component
- Motherboard
- AMD Ryzen Motherboard
- ASUS
- Asus ROG STRIX B850-F GAMING WIFI AM5 ATX Motherboard
- Stock: Out Of Stock
- Model: ROG STRIX B850-F GAMING WIFI
- Graphics Output: 1x HDMI, 1x USB Type-C
- Supported RAM: 2 x DDR5, up to 128GB, 8400+ MT/s (OC)
- Supported CPU: AMD Socket AM5 for AMD Ryzen 9000, 8000 & 7000 Series
- Features: Intel 2.5Gb Ethernet, Wi-Fi 7, Bluetooth 5.4
| Main Feature | |
| Type | DDR5 |
| Basic Information | |
| Supported CPU | AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors |
| Chipset | AMD B850 |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Form Factor | Mini-ITX Form Factor 6.7 inch x 6.7 inch (17 cm x 17 cm) |
| Audio | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| Expansion Slots | |
| PCI | AMD Ryzen 9000 & 7000 Series Desktop Processors 1 x PCIe 5.0 x16 slot with Q-Release Slim AMD Ryzen 8000 Series Desktop Processors 1 x PCIe 4.0 x16 slot with Q-Rlease Slim |
| M.2 Socket | 2 x M.2 |
| Memory Specifications | |
| Slots | 2 x DIMM |
| Supported Memory Type | 2 x DIMM slots, max. 128GB, DDR5 Supports up to 8400+MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors ECC and Non-ECC, Un-buffered DIMM Dual channel memory architecture Supports AMD Extended Profiles for Overclocking (EXPO™) ASUS Enhanced Memory Profile (AEMP) |
| Max. Memory | 128GB |
| Connector & Ports | |
| HDMI | 1x HDMI 2.1 |
| USB (s) | Rear USB (Total 8 ports) 1 x USB 20Gbps port(s) (1 x USB Type-C®) 5 x USB 10Gbps port(s) (4 x Type-A + 1 x USB Type-C®) 2 x USB 2.0 port(s) (2 x Type-A) Front USB (Total 5 ports) 1 x USB 10Gbps 1 x USB 5Gbps header(s) support(s) 2 additional USB 5Gbps ports 1 x USB 2.0 header(s) support(s) 2 additional USB 2.0 ports USB Type-C power delivery output: max. 5V/3A |
| LAN Port (s) | 1 x Intel 2.5Gb Ethernet ASUS LANGuard |
| Wireless Communication module | Wi-Fi 7* 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6GHz frequency band** Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate. Bluetooth® v5.4*** |
| Supported Storage | Total supports 2 x M.2 slots and 2 x SATA 6Gb/s ports AMD Ryzen™ 7000 & 9000 Series Desktop Processors M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 5.0x4 mode) M.2_2 (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) AMD Ryzen 8000 Series Desktop Processors M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 4.0x4 mode) M.2_2 (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)* * Specifications vary by CPU types. |
| Audio | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080* - Impedance sense for front and rear headphone outputs - Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking - High quality 120 dB SNR stereo playback output and 110 dB SNR recording input - Supports up to 32-Bit/384 kHz playback on front panel Audio Features - SupremeFX Shielding Technology - Savitech SV3H712 AMP - Rear optical S/PDIF out port - Premium audio capacitors - Audio cover * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. ** The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device. |
| Internal I/O Ports | Fan and Cooling Related 1 x 4-pin CPU Fan header 1 x 4-pin Extra Flow Fan header 1 x 4-pin AIO Pump header 1 x 4-pin Chassis Fan headers Power Related 1 x 24-pin Main Power connector 1 x 8-pin +12V CPU Power connector Storage Related 2 x M.2 slots (Key M) 2 x SATA 6Gb/s ports USB 1 x USB 10Gbps connector (supports USB Type-C®) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 headers support 4 additional USB 2.0 ports Miscellaneous 2 x Addressable Gen 2 headers 1 x CPU Over voltage jumper 1 x Front Panel Audio header (F_AUDIO) 1 x 10-1 pin Front System Panel header 1 x Thermal Sensor header Back Panel I/O Ports 1 x USB 20Gbps port(s) 5 x USB 10Gbps port(s) (4 x Type-A + 1 x USB Type-C® with DP Alt mode) 2 x USB 2.0 port(s) (2 x Type-A) 1 x HDMI™ port 1 x Wi-Fi module 1 x Intel® 2.5Gb Ethernet port 3 x Audio jacks 1 x Optical S/PDIF out port 1 x BIOS FlashBack™ button 1 x Clear CMOS button 1 x FlexKey button |
| Graphics | |
| Graphics | 1 x HDMI™ port*** 1 x USB 10Gbps ports support USB Type-C® display outputs**** * Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications. *** Supports 4K@60Hz as specified in HDMI 2.1. ****Supports max. 4K@60Hz as specified in DisplayPort 1.4a ***** VGA resolution support depends on processors' or graphic cards' resolution. |
| Features | |
| Other Features | Extreme Engine Digi+ - 5K Black metallic capacitors ASUS Q-Design - M.2 Q-Latch - M.2 Q-Slide - PCIe Slot Q-Release Slim (with PCIe SafeSlot) - Q-Antenna - Q-Dashboard - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink backplate - M.2 heatsink ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - Clear CMOS button - ProCool - Pre-mounted I/O shield - SafeSlot - SafeDIMM Aura Sync - Addressable Gen 2 headers |
| Others Information | |
| Bundled Software | ROG Exclusive Software - ROG CPU-Z - Dolby Atmos ASUS Exclusive Software Armoury Crate - AIDA64 Extreme (60 days free trial) - Aura Creator - Aura Sync - Fan Xpert 4 - GameFirst - HWiNFO - Power Saving ASUS DriverHub ASUS GlideX TurboV Core Adobe Creative Cloud (Free Trial) Norton 360 for Gamers (60 Days Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode - ASUS MyHotkey |
| Warranty Information | |
| Manufacturing Warranty | 3 Years Warranty |
Asus ROG STRIX B850-F GAMING WIFI AM5 ATX Motherboard
The Asus ROG STRIX B850-F GAMING WIFI AM5 Motherboard is a powerful and compact Mini-ITX solution tailored for gamers and enthusiasts who want top-tier performance in a small form factor. Designed for AMD Ryzen 9000, 8000, and 7000 series desktop processors, it utilizes the AM5 socket and AMD B850 chipset, delivering next-gen speed, efficiency, and reliability for high-performance gaming builds. Despite its compact 6.7-inch Mini-ITX design, this motherboard is packed with features. It supports up to 128GB of DDR5 RAM, with speeds reaching 8400+ MT/s (OC), and features two M.2 slots (PCIe 5.0 & 4.0) along with two SATA 6Gb/s ports for high-speed storage solutions. The single PCIe 5.0 x16 slot with Q-Release Slim ensures future-ready GPU support with ease of installation. Connectivity is cutting-edge with Wi-Fi 7, Bluetooth 5.4, and Intel 2.5Gb Ethernet, ensuring ultra-fast and stable networking. It includes a total of 13 USB ports across the front and rear, with USB 20Gbps Type-C, multiple USB 10Gbps, and Type-C with DP Alt mode for display output. Display connectivity is further enhanced by HDMI 2.1, supporting up to 4K@60Hz. Audio quality is elite thanks to ROG SupremeFX ALC4080 with 7.1 Surround Sound, premium capacitors, and Savitech amp, delivering immersive and detailed sound. DIY-friendly features include BIOS FlashBack™, Clear CMOS, Q-LED diagnostic lights, Aura Sync RGB headers, and pre-mounted I/O shield. With advanced thermal solutions like M.2 heatsinks and fan headers, combined with ASUS-exclusive software such as Armoury Crate and Fan Xpert 4, the ROG STRIX B850-F balances performance, aesthetics, and ease of use. It’s backed by a 3-year warranty, making it a reliable core for any compact, high-end gaming setup.
