Name: ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard
Brand: ASRock
Price: 20500.00 BDT
Availability: InStock
Rating: 5 (1 reviews)

Specification

Basic Information
Supported CPU	Supports AMD Socket AM5 Ryzen 9000, 8000 and 7000 Series Processors
Chipset	AMD B650
BIOS	- 256Mb AMI UEFI Legal BIOS with GUI support
Form Factor	- Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm - 2oz Copper PCB
Audio	- 7.1 CH HD Audio (Realtek ALC897 Audio Codec) - Nahimic Audio
Expansion Slots
PCI	CPU: - 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode* - 1 x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode* Chipset: - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module - Supports AMD CrossFire - 15μ Gold Contact in VGA PCIe Slot (PCIE1)
Memory
Slot	- 4 x DDR5 DIMM Slots
Supported Memory	- Dual Channel DDR5 Memory Technology - Supports DDR5 ECC/non-ECC, un-buffered memory up to 7200+(OC)* - Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
Memory Type	DDR5
Maximum Memory	Max. 256GB
Memory Specifications
Slots
Max. Memory
Connector & Ports
HDMI	1x HDMI
Display Port (s)	1x DisplayPort 1.4
USB (s)	- 1 x USB 3.2 Gen2 Type-C (Rear) - 1 x USB 3.2 Gen2 Type-A (Rear) - 1 x USB 3.2 Gen1 Type-C (Front) - 6 x USB 3.2 Gen1 Type-A (2 Rear, 4 Front) - 8 x USB 2.0 (4 Rear, 4 Front)
LAN Port (s)	- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s - Dragon RTL8125BG - Supports Dragon 2.5G LAN Software - Smart Auto Adjust Bandwidth Control - Visual User Friendly UI - Visual Network Usage Statistics - Optimized Default Setting for Game, Browser, and Streaming Modes - User Customized Priority Control
Wireless Communication module	- 802.11ax Wi-Fi 6E Module - Supports IEEE 802.11a/b/g/n/ac/ax - Supports Dual-Band 2x2 with extended 6GHz band* support - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology - Supports Bluetooth 5.2 + High speed class II - Supports MU-MIMO
Supported Storage	CPU: - 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen5x4 (128 Gb/s) mode* Chipset: - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* - 1 x M.2 Socket (M2_3, Key M), supports type 2260/2280 PCIe Gen4x2 (32 Gb/s) mode* - 4 x SATA3 6.0 Gb/s Connectors
Audio	3 x Audio jacks
Internal I/O Ports	Rear Panel I/O - 2 x Antenna Mounting Points - 1 x HDMI Port - 1 x DisplayPort 1.4 - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) - 2 x USB 3.2 Gen1 Ports - 4 x USB 2.0 Ports - 1 x RJ-45 LAN Port - 1 x BIOS Flashback Button - HD Audio Jacks: Line in / Front Speaker / Microphone Connector - 1 x Power LED and Speaker Header - 1 x RGB LED Header* - 3 x Addressable LED Headers - 1 x CPU Fan Connector (4-pin)* - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)** - 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*** - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) - 1 x Front Panel Audio Connector - 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 4 AIC Card) - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) - 1 x Front Panel Type C USB 3.2 Gen1 Header
RAID	- Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices - Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices
TPM (Trusted Platform Module )	- 1 x SPI TPM Header
Graphics
Graphics	Integrated AMD RDNA graphics (Actual support may vary by CPU) - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz - 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz
Max Shared Memory
Others
Bundled Software	Software - ASRock Motherboard Utility (A-Tuning) - ASRock Dragon 2.5G LAN Software - ASRock Polychrome SYNC* UEFI - ASRock Full HD UEFI - ASRock Auto Driver Installer - ASRock Instant Flash
Special Features	Superb Productivity - PCIe Gen5 (M.2) - Dual Channel DDR5 Rock-Solid Durability - 8+2+1 Power Phase, 50A Dr.MOS - Pre-Installed I/O Shield Ultrafast Connectivity - 2.5G LAN EZ Update - BIOS Flashback Button - ASRock Auto Driver Installer
Warranty Information
Manufacturing Warranty	3 Years

Description

ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard – Balanced Performance with Built-In WiFi

The ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard is a solid and feature-rich platform designed for AMD Ryzen 7000 series desktops. Built with the AM5 socket and support for DDR5 memory, it delivers responsive performance across gaming, productivity, and everyday computing tasks. The Micro ATX form factor makes it suitable for compact builds while still offering important expandability. With integrated WiFi, PCIe 4.0 support for graphics and high-speed NVMe SSDs, multiple M.2 slots, and versatile USB connectivity, this motherboard provides a reliable foundation for modern AMD PC systems in Bangladesh.

Key Features of ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard

AM5 socket with support for AMD Ryzen 7000 series CPUs
DDR5 memory compatibility for faster performance
Built-in WiFi for easy wireless networking
PCIe 4.0 slots for graphics and SSD expansion
Multiple M.2 NVMe SSD slots
USB 3.x high-speed ports for peripherals
Micro ATX form factor for compact systems

Advanced DDR5 Memory Support

This motherboard supports high-speed DDR5 RAM, offering improved data bandwidth and system responsiveness, which is great for multitasking, gaming, and content creation.

Compact Yet Expandable Design

The Micro ATX design provides a space-efficient layout without sacrificing key expansion options like M.2 storage and PCIe connectivity, making it ideal for small and mid-size PC builds.

Why Choose ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard?

This board is a smart choice for builders seeking a feature-packed AMD platform with built-in WiFi, next-gen memory support, and reliable performance in a compact form factor — perfect for balanced gaming and productivity systems.

Benefits of ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard

Future-ready AM5 support for Ryzen CPUs
Enhanced system speed with DDR5 memory
Convenient wireless connectivity with built-in WiFi
Fast storage and graphics support with PCIe 4.0
Ideal for compact and efficient PC builds

Frequently Asked Questions (FAQ)

Q1: Does this motherboard support AMD Ryzen 7000 series processors?

A1:Yes, it supports AMD Ryzen 7000 series and AM5 compatible CPUs.

Q2: Does it include built-in WiFi?

A2:Yes, it has integrated WiFi for wireless internet access.

Q3: What memory type does this motherboard support?

A3:It supports high-speed DDR5 desktop memory modules.https://www.onixbd.com/asrock-amd-ryzen-motherboard
