Model: WAX220
View More Info...
Chat Through
| LED Type | LED Indicators LED Indicators LED Indicators LED Indicators: 4 LEDs (Power, LAN, 2.4GHz, 5GHz) |
| Wireless | Security Protocols: WPA/WPA2/WPA3 Band: Dual Frequency: 2.4GHz, 5GHz Bluetooth: No Antenna (Type & Qty): Unmentioned Antenna Gain: 3.1/4.3 dBi Antenna Placement: Internal MU-MIMO Support: Yes Multi-User MIMO: Yes Wireless Modes: 4x4 in 5.0GHz, 4x4 in 2.4GHz |
| Network Standard | IEEE 802.11ax IEEE 802.11ac specification IEEE 802.11n 2.0 specification IEEE 802.11g IEEE 802.11b IEEE 802.11a |
| Operating Temperature | 0° to 40°C (32° to 104°F) |
| Weight | 1.15lb (523g) |
| Data Transmission Rate | 600Mbps (2.4GHz) 3600Mbps (5.0GHz) |
| Dimensions | 7.71x7.71x1.74 in (196x196x44.4 mm) |
| Interface | 100/1000/2500Mbps Ethernet (RJ-45) PoE port with Auto Uplink (Auto MDI-X) Number of LAN Port: 1 |
| LAN | 100/1000/2500Mbps Ethernet (RJ-45) PoE port with Auto Uplink (Auto MDI-X) |
| Power | 12V/2.5V (30W) Power adapter (included with WAX220PA model only) or PoE+ Switch |
| Power Consumption | 15.2W |
| Warranty | 3 Year |
The NETGEAR WAX220 WiFi 6 AX4200 Dual Band Access Point is a high-performance networking solution designed for businesses, offices, and high-demand home environments. With advanced WiFi 6 (IEEE 802.11ax) technology, this access point delivers blazing-fast wireless speeds, greater capacity, and improved efficiency compared to previous generations. It supports multiple network standards, including IEEE 802.11ac, 802.11n 2.0, 802.11g, 802.11b, and 802.11a, ensuring compatibility with a wide range of devices. Equipped with a 100/1000/2500Mbps Ethernet (RJ-45) PoE port with Auto Uplink (Auto MDI-X), the WAX220 can be powered using PoE+ for simplified installation without the need for a separate power adapter. For models like the WAX220PA, a 12V/2.5V (30W) power adapter is included. It also offers a power consumption rate of 15.2W, making it energy-efficient.
This dual-band access point provides 600Mbps on the 2.4GHz band and 3600Mbps on the 5GHz band, with support for MU-MIMO and OFDMA for simultaneous, high-speed connections to multiple devices. Its internal antennas offer a gain of 3.1/4.3 dBi, ensuring strong and stable coverage. Security is top-tier, featuring WPA/WPA2/WPA3 protocols, MAC address filtering, and up to 4 SSIDs for network segmentation. The WAX220 is built for reliability, with an MTBF of over 1,896,453 hours at 25°C and 431,098 hours at 45°C. It is compact and lightweight, measuring 196x196x44.4 mm and weighing only 523g, making it easy to mount and blend into any environment. The device operates between 0°C to 40°C, making it suitable for most indoor conditions. LED indicators for power, LAN, and both frequency bands provide clear visual status updates, while the internal design ensures a clean, professional look. The WAX220 also includes a 3-year warranty (excluding the adapter), giving users confidence in its long-term performance. Ideal for modern offices, educational institutions, retail environments, and advanced home setups, the NETGEAR WAX220 WiFi 6 AX4200 Dual Band Access Point with Multi-Gig PoE delivers unmatched wireless performance, advanced security, and versatile connectivity all in a compact, easy-to-deploy package.
