IMAGE SENSOR
| - Type: Approx. 22.3 mm x 14.9 mm
- Pixels: Approx. 18.0 megapixels
- Aspect Ratio: 3:2
|
Other Features
| |
FOCUSING
| - AF Point: Via optical viewfinder: 9 AF points (f/5.6 cross type at centre)
- Modes: Via optical viewfinder: AI Focus (Switches between One-Shot AF and AI SERVO AF automatically), One Shot AF, AI Servo, Manual, Via live view LCD screen: One Shot AF (Contrast detect AF), Quick Mode (via phase detection AF sensor), Manual
|
EXPOSURE CONTROL
| - Metering Modes: Via optical viewfinder: Evaluative via 63 zone dual-layer metering sensor (linked to all AF points), Partial (centre, approx. 10% of viewfinder), Centre-weighted average available, Via live view on LCD screen: Evaluative metering (315 zones)
- ISO Sensitivity: AUTO(100-6400), 100-6400 in 1-stop increments ISO can be expanded to H: 12800 1, During Movie shooting: Auto (100-6400), 100-6400 (Whole stop increments)
|
SHUTTER
| - Shutter Speed: 30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
|
SHOOTING
| - Color Space: sRGB and Adobe RGB
- Continuous Shooting: Max. Approx. 3 fps in JPEG until memory card becomes full 4, 6 images RAW
|
FILE TYPE
| - Image Type: JPEG: Fine, Normal (Exif 2.30 compliant) / Design rule for Camera File system (2.0), RAW: RAW (14bit, Canon original RAW 2nd edition), Digital Print Order Format [DPOF] Version 1.1 compliant
- Image Size: JPEG 3:2: (L) 5184 x 3456, (M) 3456 x 2304, (S1) 2592 x 1728, (S2) 1920 x 1280, (S3) 720 x 480, JPEG 4:3: (L) 4608 x 3456, (M) 3072 x 2304, (S1) 2304 x 1728, (S2) 1696 x 1280, (S3) 640 x 480, JPEG 16:9: (L) 5184 x 2912, (M) 3456 x 1944, (S1) 2592 x 1456 (S2) 1920 x 1080, (S3) 720 x 400, JPEG 1:1: (L) 3456 x 3456, (M) 2304 x 2304, (S1) 1728 x 1728, (S2) 1280 x 1280, (S3) 480 x 480, RAW: (RAW) 5184 x 3456
- Movie Type: MOV (Video: H.264 inter frame (IPB), Sound: Linear PCM, recording level can be manually adjusted by user)
- Movie size: 1920 x 1080 (30, 25, 24 fps), 1280 x 720 (60, 50 fps), 640 x 480 (30, 25 fps)
|
LCD MONITOR
| - Type: 6.8 cm (2.7") TFT LCD, approx. 230 K dots
- Viewing Angle: Approx. 120° vertically, Approx. 130° horizontally
|
STORAGE
| - Storage Type: SD card, SDHC card or SDXC card
|
FLASH
| - Built-in Flash: 9.2
- External Flash Compatibility: E-TTL II with EX series Speedlites
|
POWER SOURCE
| - Batteries: 1 x Rechargeable Li-ion Battery LP-E10
|
PHYSICAL SPECIFICATIONS
| - Dimensions (W x H x D): 129.0 x 101.6 x 77.1 mm
- Weight (Body Only): Approx. 436 g (CIPA testing standard, including battery and memory card)
|
LENS
| - Lens Mount: EF-S 18-55mm f/3.5-5.6 III Lens
- Focal Length: Equivalent to 1.6x the focal length of the lens
- Maximum Aperture: Shutter Priority; Aperture Priority
|
